상세설명
공기순환팬
초대형 천정형 선풍기
M600 Specifications
| Models / Performance | M600-8 | M600-10 | M600-12 | M600-14 |
|---|---|---|---|---|
| Diameters | 2440 mm | 3050 mm | 3660 mm | 4270 mm |
| Number of Blades | 5 | 5 | 5 | 5 |
| Weight | 26 kg | 29 kg | 32 kg | 35 kg |
| Max Rotation Speed | 122 RPM | 122 RPM | 98 RPM | 74 RPM |
| Max Airflow (AMCA 230-15) * | 33,090 m³/h | 77,300 m³/h | 115,360 m³/h | 136,250 m³/h |
| Max Airflow (AMCA 230-99) * | 46,795 m³/h | 109,320 m³/h | 163,145 m³/h | 192,288 m³/h |
| Power Usage (Average) | 85 Watts | 155 Watts | 240 Watts | 190 Watts |
| Covered Area (m2) | 180 m² | 230 m² | 350 m² | 470 m² |
| Recommended Blade Height (m) | 5-7 m | 5-7 m | 5-7 m | 5-7 m |
* Airflow have been tested per AMCA 230-15 & 230-99 standards.
| General specifications | |
|---|---|
| Voltage | 110VAC - 240VAC Single Phase, 50Hz / 60Hz |
| Sound @ Max Speed | <40 dBA |
| IP Rating | Indoor Rated (Outdoor Rating 2019) |
| Temperature Rating | -10C / +50C with Safety Slowdown |
| Certifications | CE, CB for local IEC Certification |
| Controller | 7" HMI for 1-10 Fans (Sold separate) |
| Mounting | Fully Ajustable. No Guy Wires with standard drop tube. |
| Mount to Blades Height | 1m Standard |
| Warranty | 3 Years on all Parts - Extended Warranty Optional |
M700 & M800 Specifications
| Models / Performance | M700-14 | M700-16 | M700-18 | M700-20 | M700-24 | M800-24 |
|---|---|---|---|---|---|---|
| Diameters | 4267 mm | 4877 mm | 5486 mm | 6096 mm | 7315 mm | 7315 mm |
| Number of Blades | 5 | 5 | 5 | 5 | 5 | 5 |
| Weight | 86 kg | 90 kg | 95 kg | 99 kg | 104 kg | 113 kg |
| Max Rotation Speed | 84 RPM | 78 RPM | 69 RPM | 53 RPM | 37 RPM | 49 RPM |
| Max Airflow (AMCA 230-15) * | 198,867 m³/h | 240,774 m³/h | 270,214 m³/h | 311,216 m³/h | 358,747 m³/h | 508,825 m³/h |
| Max Airflow (AMCA 230-99) * | 281,198 m³/h | 340,453 m³/h | 382,082 m³/h | 440,497 m³/h | 507,268 m³/h | 719,478 m³/h |
| Power Usage (Average) | 500 Watts | 780 Watts | 830 Watts | 630 Watts | 400 Watts | 950 Watts |
| Covered Area (m2) | 460 | 600 | 760 | 930 | 1000 | 1330 |
| Recommended Blade Height (m) | 7-10 m | 7-10 m | 7-10 m | 7-10 m | 7-10 m | 7-10 m |
* Airflow have been tested per AMCA 230-15 & 230-99 standards.
| General Specs. | M700 & M800 |
|---|---|
| Voltage (50- 60Hz) | 208VAC - 240VAC Single Phase |
| Noice @ Max Speed | <50 dBA |
| IP Rating | Indoor Rated |
| Temperature Rating | -10C / +50C with Safety Slowdown |
| Certifications | CE, CB for local IEC Certification |
| Controller | 7" HMI for 1-10 Fans (Sold separate) |
| Mounting | Fully adjustable mount without guide wires up to 1m drop tube. |
| Mount to Blades Height | 1m Standard |
| Warranty |
3 Years on all Parts - Extended Warranty Optional |
