Construction

Single-impeller submersible pumps in chrome-nickel stainless steel, with vertical delivery port.

GXR: with open impeller.

GXV: with free-flow (vortex) impeller.

Motor cooled by the pumped water passing between the motor jacket and the external jacket.

Double shaft seal with oil chamber.

Applications

GXR : - For clean water containing solids up to 10 mm grain size.

          - For draining rooms or or emptying tanks.

          - Extraction of water from ponds, streams or pits and for rainwater collection.

          - For irrigation purposes.

GXV : - For clean or slightly dirty water, containing solids up to 25 mm grain size.

          - Particularly suitable for liquids with a high solid content.

For outdoor use a power supply cable of not less than 10 m should be usedin accordance with : EN 60 335-2-41.

Operating conditions

Liquid temperature up to 50° C.

Maximum immersion depth : 5 m.

Minimum water level with float : GXR = 70 mm, GXV = 130 mm.

Minimum water level manual operation : GXR = 15 mm, GXV = 30 mm.

Continuous duty.
