Construction

Close-coupledperipheral pumps (regenerative pumps) with turbine impeller.

Connections : threaded ports ISO 228/1.

                  threaded ports NPT(ANSI/ASME B1.20.1) on request

T, TP: version with pump casing and lanter bracket in cast iron.

B-T, B-TP:version with pump casing and lanter bracket in bronze (the pumps are supplied fully painted).

Applications

For clean liquids without abrasives, without suspendedsolids, non-explosive, non-aggressive for the pump materials.

For increasing network pressure (follow local specifications).

For the reduced dimensions, these pumps are very well suitable to be mounted in cooling and air-conditioning machines and equipments, circulation, boiler feed.

Operating conditions

Liquid temperature from -10 °C to +90 °C.

Ambient temperature up to 40 °C.

Total suction lift up to 7 m.

Continuous duty.
