Construction

Close-coupled self-priming shallow-well jet pump with built-in ejector.

Connections : threaded ports ISO 228/1.

                  threaded ports NPT(ANSI/ASME B1.20.1) on request

Applications

For drawing water out of a well.

For lifting water containing air or other gases.

For increasing water pressure from flooded suction applications.

As pressure boosting pump for central water systems with low pressure (follow local specifications if increasing network pressure).

For garden use.

For washing with a jet of water.

Operating conditions

Liquid temperature: 0 °C to +35 °C.

Ambient temperature up to +40 °C.

Maximum permissible pressure in the pump casing: 8 bar.

Continuous duty.
