Construction

Close-coupledself-priming centrifugal pumps  with built-in strainer. Connections : threaded ports ISO 228/1.

                  threaded ports NPT(ANSI/ASME B1.20.1) on request

NMP: version with pump casing and lanter bracket in cast iron.

B-NMP: version with pump casing and lanter bracket in bronze(the pumps are supplied fully painted).

Applications

For water circulation in swimming pool filtration systems.

For clean or slightly dirty water with solids in suspension.

Operating conditions

Liquid temperature up to 60° C.

Ambient temperature up to 40° C.

Total suction lift up to 7 m.

Maximum permissible working pressure up to 6 bar.
