Speed (rpm) : 160,000

Frequency (Hz) : 2,666

Voltage (V) : 200

MAX current (A) : 4.1

Power (Kw) : 0.75

Torque (N•m) : 0.12

Body diameter (mm) : 62

Collet type : ATC

Collet torque (N•cm) : ≥300

Tool clamping range (mm) : φ3.175

Collet actuation pressure (kgf/㎠) : 5, 6

Dynamic axial run-out (㎛) : ≤10

Radial failure load (kgf) : ≥7.0

Axial failure load push (kgf) : ≥23

Axial failure load pull (kgf) : ≥17

Working air pressure (kgf/㎠) : 6.0~6.5

Vibration (mm/s) : ≤1.1
