Construction

Close-coupledcentrifugal pumps with open impeller.

Free-flow impeller (vortex or recessed impeller) for type C 16/1E.

Connections:threaded ports ISO 228/1.

                     threaded ports NPT(ANSI/ASME B1.20.1) on request

C: version with pump casing and lanter bracket in cast iron.

B-C:version with pump casing and lanter bracket in bronze

        (the pumps are supplied fully painted).

Applications

For moderately dirty liquids or emulsions.

For industry and agriculture.

Operating conditions

Liquid temperature from -10 °C to +90 °C.

Ambient temperature up to 40 °C.

Total suction lift up to 8 m.

Maximum permissible working pressure: 6 bar.

Maximum size of solids: 4 mm.

Continuous duty.
