Construction

Close-coupled centrifugal pumps with open impeller. Free-flow impeller (vortex or recessed impeller) for type C 16/1E.

C: version with pump casing and lantern bracket in cast iron.

B-C: version with pump casing and lantern bracket in bronze

       (the pumps are supplied fully painted).

Applications

For moderately dirty liquids or emulsions.

For industry and agriculture.

Operating conditions

Liquid temperature from -10 °C to +90 °C.

Ambient temperature up to 40 °C.

Total suction lift up to 8 m.

Maximum permissible working pressure: 6 bar.

Maximum size of solids: 4 mm.

Continuous duty.
