Construction

Horizontal multi-stage close coupled pump.

Single-piece barrel casing in chrome-nickel stainless steel, with front suction port above pumps axis and radial delivery at top.

Stages in Noryl.

Connections: threaded ports ISO 228/1.

                      threaded ports NPT (ANSI/ASME B1.20.1) on request.

Applications

For water supply.

For domestic use, for garden use and irrigation.

Operating conditions

Liquid temperature: 0 °C  to +50 °C.

Ambient temperature up to +40 °C.

Maximum permissible pressure in the pump casing: 8 bar.

Continuous duty.
