Construction

Close-coupled, centrifugal pumps; electric motor with extended shaft directly connected to the pump. NM: single-impeller

NMD: with two back-to-back impellers (with axial thrust balancing).

Connections: threaded ports ISO 228/1.

                      threaded ports NPT (ANSI/ASME B1.20.1) on request

NM, NMD: version with pump casing and lantern bracket in cast iron. B-NM, B-NMD: version with pump casing and lantern bracket in bronze. (the pumps are supplied fully painted).

Applications

-For clean liquids without abrasives, which are, non-aggressive  for the pump materials ( solids content up to 0.2%).

- For water supply.

- For heating, air-conditioning, cooling and circulation plants.

- For civil and industrial applications.

- For fire fighting applications.

- For irrigation.

Operating conditions

Liquid temperature from -10 °C to +90 °C.

Ambient temperature up to 40 °C.

Total suction lift up to 7 m.

Maximum permissible working pressure up to 10 bar (16 bar for pumps NMD 25/190; NMD 32/210; NMD 40/180). Continuous duty.
