Super Precision Angular Contact Ball Bearings
NSK는 용도에 따라 최적의 사양을 선택할 있도록, 다양한 초정밀 앵귤러 볼 베어링(Super Precision Angular Contact Ball Bearings)을 시리즈를 구비하고 있습니다. NSK 초정밀 앵귤러 볼 베어링은 공작 기계의 회전축과 같은, 매우 빠른 회전속도에서 높은 수준의 정밀성이 요구되는 각종 기계장치에 매우 적합합니다.
특징
- ISO 규격에 맞춘 basic시리즈와 공작기계용 시리즈가 있습니다
- 그리스가 밀봉되어 있는 제품도 있습니다. .
- 고성능 Robust 베어링 시리즈는 강도에 특화된 제품에서 초고속용까지 다양한 제품 라인업이 준비되어 있습니다.
-
- Standard Series of High Precision Angular Contact Ball Bearings
-
A basic series of NSK precision Angular Contact Ball Bearings that meets ISO standards.
Features:
- NSK's Z steel, a long life bearing steel, is used as the standard material.
- The 70 and 79 series are sealed with a grease life that has been improved by one and half times.
- Two types of cages are available.
-
- Robust Series of Ultra High-Speed Angular Contact Ball Bearings
-
This series developed with the best of material, evaluation, and analysis technologies, of which NSK is proud. This is highly functional series for machine tool. In addition, the sealed type of this series, which offers longer service life and shows excellent environmental friendliness is available.
Features:
- Reduces heat generation and achieves high-speed rotation
- X type bearing, which is made of SHX steel developed by NSK, offers long service life for use in high-speed applications.
- Wide lineup to meet various applications is achieved.
- Grease life of the selaed type has been extended.
-
- Robust series, Spinshot II of Ultra High-Speed Angular Contact Ball Bearings with Oil-Air Lubrication
-
Ultra High-Speed rotation and low-noise performance has been achieved through focusing efforts on optimizing the oil-air lubrication system of this bearing.
Features:
- Achieves 40,000 min-1 with ISO-40 equivalent taper using oil-air lubrication.
- Noise levels reduced by approximately 3 dB to 5 dB in comparison with conventional oil-air lubrication.
- Achieves 40,000 min-1 with about half of the air volume of conventional oil-air lubrication.
-
- Robust BGR series of Ultra High Precision Angular Contact Ball Bearings
-
Accommodate the need for high precision and ultra high-speed for shaft diameters of less than 30 mm.
Highly functional series that support the high performance requirements of compact spindles.Features:
- Ultra high-speed bearings designed specifically for compact spindles.
- X-type with inner and outer rings that are made of excellent heat resistant and wear resistant SHX steel help high-speed applications achieve a long service life.
- High precision specifications are standard.
-
- Robust Series of High-Speed Angular Contact Thrust Ball Bearings
-
A Robust series of Angular Contact Ball Bearings for sustaining axial loads that achieves high-speed and high rigidity performance.
Features:
- The BTR series has a contact angle of 40° that features both high thrust rigidity and low heat generation properties.
- The BAR series has a contact angle of 30° that focuses on high-speed performance in comparison to the BTR series.
-
- TAC-F Series of Highly Rigid Angular Contact Thrust Ball Bearings
-
The TAC-F series of Angular Contact Ball Bearings is used to sustain axial loads and is focused on high rigidity.
Features:
- A contact angle of 50° that focuses on rigidity, and perfect for highly rigid spindles that operated under heavy-duty cutting applications.
- Inseparable design facilitates easier handling.
