Encoders Absolute multiturn

Sendix M3668









Encoders, bearingless encoders and motor feedback systems

Rotative speed measurement and position detection. Optical or magnetic. Incremental or absolute

Intelligent Scan Technology™ – powerful and economical at the same time.

The absolute encoders multiturn Sendix F3668 / F3688 with patented Intelligent Scan Technology™ and CANopen interface are characterized by special robustness and compactness. With dimensions of only 36 x 42 mm, a shaft or blind hollow shaft up to 10 mm is available. The high-precision optical sensor technology achieves a resolution of up to 16 bit singleturn and up to 16 bit multiturn.

• Dimension

  Ø 36 mm

  Resolution

  16 bits singleturn

  16 bits multiturn

  Shaft type

  Max 10 mm shaft, with flat surface

  Max 3/8" shaft, with flat surface.

  High precision Particularly resistant Without gear with 100% magnetic insensitivity

  Dimension Ø 36 mm 16 bits singleturn 16 bits multiturn Max 10 mm shaft, with flat surface Max 3/8" shaft, with flat surface
