여기에마켓 제품 :: 콤프코리아

가격 가격협의

모델명 CK SERIES

제품분류 모터/펌프/콤프레셔

업체명 콤프코리아

전화번호 0504-0667-3274

등록일 22.12.07

Model	Bar	Capacity		KW	HP	윤활유량 (L)	토출구경 A(inch)	Dimension (L×W×H)mm	Weight (kg)
Model	Bar	m³/min	cfm	KW	HP	윤활유량 (L)	토출구경 A(inch)	Dimension (L×W×H)mm	Weight (kg)
CK 450	8	3.9	137.7	30	40	18	25A(1")	1,300 x 660 x 1,325	560
CK 450	13	3.6	127.1	30	40	18	25A(1")	1,300 x 660 x 1,325	560
CK 660	8	6.11	215.8	37	50	20	40A (1 1/2")	1,550 x 800 x 1,630	820
CK 660	13	4.58	161.7	37	50	20	40A (1 1/2")	1,550 x 800 x 1,630	820
CK 660 PLUS	8	7.42	262	45	60	20	40A (1 1/2")	1,550 x 800 x 1,630	850
CK 660 PLUS	13	6	211.9	45	60	20	40A (1 1/2")	1,550 x 800 x 1,630	850
CK 1020	8	8.83	311.8	55	75	40	50A (2")	2,100 x 990 x 1,800	1530
CK 1020	13	7.1	250.7	55	75	40	50A (2")	2,100 x 990 x 1,800	1530
CK 1380	8	12.7	448.5	75	100	40	50A (2")	2,100 x 990 x 1,800	1710
CK 1380	13	9.63	340.1	75	100	40	50A (2")	2,100 x 990 x 1,800	1710
CK 2120	8	18.5	653.3	110	150	80	65A ( 2 1/2")	2,300 x 1,300 x 2,225	3200
CK 2120	13	13.52	477.5	110	150	80	65A ( 2 1/2")	2,300 x 1,300 x 2,225	3200
CK 2720	8	25.8	911.1	160	200	100	80A (3")	2,500 x 1,800 x 2,125	3400
CK 2720	13	18.2	642.7	160	200	100	80A (3")	2,500 x 1,800 x 2,125	3400
CK 2720+	8	28.3	999.4	185	250	100	80A (3")	2,400 x 1,800 x 2,024	3600
CK 2720+	13	22	904	185	250	100	80A (3")	2,400 x 1,800 x 2,024	3600
CK 4120	8	35.6	1257.2	225	300	150	100A (4")	3,550 x 1,850 x 2,245	4800
CK 4120	13	27.7	978	225	300	150	100A (4")	3,550 x 1,850 x 2,245	4800
CK 4120+	8	43.2	1525.6	265	350	200	100A (4")	3,550 x 1,850 x 2,245	5200
CK 4120+	13	34.5	1218	265	350	200	100A (4")	3,550 x 1,850 x 2,245	5200
CK 4760	8	56.3	1,988	330	450	300	150A (6")	4,440 x 1,900 x 2,300	6,000
CK 4760	13	42	1483	330	450	300	150A (6")	4,440 x 1,900 x 2,300	6,000

13bar 사양은 별도문의

- 전압/주파수 Voltage/Frequency : 220,380,440V / 50,60Hz
