상세설명
|
주요치수 (mm) |
호칭번호 |
||||
|
d |
D |
B |
r |
r1 |
|
|
10 |
26 |
8 |
0.5 |
0.3 |
7000 A |
|
|
26 |
8 |
0.5 |
0.3 |
7000 B |
|
26 |
8 |
0.5 |
0.3 |
7000 C |
|
|
30 |
9 |
1 |
0.5 |
7200 A |
|
|
30 |
9 |
1 |
0.5 |
7200 B |
|
|
30 |
9 |
1 |
0.5 |
7200 C |
|
|
35 |
11 |
1 |
0.5 |
7300 A |
|
|
35 |
11 |
1 |
0.5 |
7300 B |
|
|
35 |
11 |
1 |
0.5 |
7300 C |
|
|
12 |
28 |
8 |
0.5 |
0.3 |
7001 A |
|
|
28 |
8 |
0.5 |
0.3 |
7001 B |
|
28 |
8 |
0.5 |
0.3 |
7001 C |
|
|
32 |
10 |
1 |
0.5 |
7201 A |
|
|
32 |
10 |
1 |
0.5 |
7201 B |
|
|
32 |
10 |
1 |
0.5 |
7201 C |
|
|
37 |
12 |
1.5 |
0.8 |
7301 A |
|
|
37 |
12 |
1.5 |
0.8 |
7301 B |
|
|
37 |
12 |
1.5 |
0.8 |
7301 C |
|
|
15 |
32 |
9 |
0.5 |
0.3 |
7002 A |
|
|
32 |
9 |
0.5 |
0.3 |
7002 B |
|
32 |
9 |
0.5 |
0.3 |
7002 C |
|
|
35 |
11 |
1 |
0.5 |
7202 A |
|
|
35 |
11 |
1 |
0.5 |
7202 B |
|
|
35 |
11 |
1 |
0.5 |
7202 C |
|
|
42 |
13 |
1.5 |
0.8 |
7302 A |
|
|
42 |
13 |
1.5 |
0.8 |
7302 B |
|
|
42 |
13 |
1.5 |
0.8 |
7302 C |
|
|
17 |
35 |
10 |
0.5 |
0.3 |
7003 A |
|
|
35 |
10 |
0.5 |
0.3 |
7003 B |
|
35 |
10 |
0.5 |
0.3 |
7003 C |
|
|
40 |
12 |
1 |
0.5 |
7203 A |
|
|
40 |
12 |
1 |
0.5 |
7203 B |
|
|
40 |
12 |
1 |
0.5 |
7203 C |
|
|
47 |
14 |
1.5 |
0.8 |
7303 A |
|
|
47 |
14 |
1.5 |
0.8 |
7303 B |
|
|
47 |
14 |
1.5 |
0.8 |
7303 C |
|
