상세설명
| Travel Angle : | 30˚ |
|---|---|
| Voltage : | 24V |
| Inductance(φ:0˚) : | 22mH |
| DC resistance(@20˚C) : |
26Ω |
■ SPECIFICATION
| Travel angle | 30˚ |
|---|---|
| Voltage | 24V(duty rate 20% or less) |
| DC resistance(@20˚C) | 26Ω |
| Inductance(φ=0˚) | 22mH |
| Time constant of temperature rise |
5 minutes |
| Heat resistance class | Class F (155˚C) |
| Insulation resistance | DC 500V MEGA, Over 100MΩ |
| Dielectric strength | AC 1000V, 50/60Hz, 1minute |
| Rotor inertia | 12g-cm² |
| Mass | 900g |
| Non-energized holding torque |
15mN-m |
| Response characteristics (No-load,horizontally placed) |
6ms at 24V |
