상세설명
Electiro-optical Characteristics
| P/N | Color | IF(mA) | VF(V) | IV(mcd) | CIE/λD(nm) | 2θ1/2 (Degree) |
||
|---|---|---|---|---|---|---|---|---|
| Min. | Typ. | Typ. | Min. | Max. | ||||
| NCL-1608WH-2E1 | WHITE | 5 | 2.7 | 2.9 | 130 | 0.280 0.240 |
0.340 0.390 |
120 |
| NCL-1608BL-2E1 | BLUE | 5 | 2.7 | 2.9 | 40 | 460 | 470 | 120 |
| NCL-1608BL-2E1_C | 5 | 2.7 | 2.9 | 15 | 465 | 475 | 120 | |
| NCL-1608GN-2E1 | GREEN | 5 | 2.5 | 2.8 | 300 | 515 | 530 | 120 |
| NCL-1608GN-2E1_C | 5 | 2.6 | 2.9 | 50 | 525 | 540 | 120 | |
| NCL-1608RE-2E1 | RED | 5 | 1.7 | 1.9 | 40 | 619 | 629 | 120 |
| NCL-1608RD-2E1 | 5 | 1.7 | 1.9 | 35 | 624 | 634 | 120 | |
| NCL-1608RD-2E1_R | 5 | 1.7 | 1.9 | 80 | 619 | 629 | 120 | |
| NCL-1608OR-2E1 | ORANGE | 5 | 1.7 | 1.9 | 55 | 600 | 610 | 120 |
| NCL-1608YE-2E1 | YELLOW | 5 | 1.7 | 1.9 | 35 | 585 | 595 | 120 |
| NCL-1608YG-2E1 | YELLOW GREEN | 5 | 1.7 | 1.9 | 12 | 566 | 574 | 120 |
