상세설명
[Rotary type]
① Encoder : 72,000 COUNTS/REV
1Pulse 0.005deg
② Maximum speed : 2,000RPM
③ Resistance : 2.8Ω
④ Inductance : 0.055mH
⑤ Peak torque : 40mNm(24Vdc)
⑥ Rate torque : 7mNm
⑦ Pole pairs per revolution : 2
⑧ Peak current : 1A
⑨ Continuous stall current : 0.6A
[Linear type]
① Encoder : 0.1μm
② Linear stroke : 20mm
③ Peak force : 4N
④ Force constant : 1.8N/0.6A
⑤ Resistance : 8.7Ω
⑥ Peak current : 1.8A
⑦ Continuous stall current : 0.6A
⑧ Magnetic pitch(N-N) : 14mm
② Linear stroke : 20mm
③ Peak force : 4N
④ Force constant : 1.8N/0.6A
⑤ Resistance : 8.7Ω
⑥ Peak current : 1.8A
⑦ Continuous stall current : 0.6A
⑧ Magnetic pitch(N-N) : 14mm
