상세설명
| Model | Square Drive |
Torque | Weight | Dimensions | |||||||||||||||||
| Ft-lbs | Mm | L1 | L2 | H1 | H2 | Radius | W1 | W2 | |||||||||||||
| in | min | max | min | max | lbs | kg | in | mm | in | mm | in | mm | in | mm | in | mm | in | mm | in | mm | |
| RT-.5 | 1/2" | 55 | 397 | 75 | 538 | 0.8 | 0.4 | 3.15 | 81 | 4.87 | 125 | 2.35 | 60.5 | 3.62 | 93 | 0.52 | 13.5 | 1.3 | 33.5 | 1.97 | 50.5 |
| RT-1 | 3/4" | 200 | 1340 | 271 | 1817 | 3.8 | 1.9 | 4.68 | 120 | 7.13 | 183 | 3.52 | 90.5 | 4.75 | 122 | 0.9 | 23 | 1.95 | 50 | 2.76 | 71 |
| RT-3 | 1" | 480 | 3230 | 651 | 4379 | 7.8 | 3.9 | 6.04 | 155 | 9.24 | 237 | 4.68 | 120 | 6.08 | 156 | 1.28 | 33 | 2.59 | 66.5 | 3.72 | 95.5 |
| RT-5 | 1-1/2" | 835 | 5590 | 1132 | 7578 | 15 | 7.5 | 7.21 | 185 | 11.23 | 288 | 5.63 | 144.5 | 7.05 | 181 | 1.44 | 37 | 3.12 | 80 | 4.9 | 126 |
| RT-8 | 1-1/2" | 1200 | 8000 | 1627 | 10845 | 23 | 11.5 | 7.85 | 202 | 12.49 | 321 | 6.42 | 164.6 | 8. | 213.36 | 1.62 | 41 | 3.48 | 88 | 4.95 | 126 |
| RT-10 | 1-1/2" | 1755 | 11520 | 2379 | 15617 | 26.8 | 13.4 | 9 | 232 | 13.9 | 375 | 7.2 | 186 | 9.3 | 239 | 1.87 | 48 | 3.9 | 100 | 5.5 | 142.5 |
| RT-20 | 2-1/2" | 2960 | 19760 | 4013 | 26787 | 36 | 18 | 10.2 | 259 | 16.55 | 420 | 8.5 | 216 | 9.9 | 251 | 2.17 | 55.11 | 4.7 | 119 | 6.7 | 170 |
| RT-25 | 2-1/2" | 3960 | 25890 | 5368 | 35096 | 62 | 31 | 12 | 310 | 18.4 | 473 | 9.1 | 234 | 11 | 282 | 2.37 | 61 | 5.2 | 134 | 7.4 | 191 |
| RT-50 | 2-1/2" | 7875 | 52500 | 10675 | 71169 | 96 | 48 | 15.2 | 390 | 23.9 | 615 | 11.4 | 294 | 13.4 | 344 | 30.8 | 79 | 6.5 | 167 | 8.9 | 228 |
