| Model | KDB3008AHW | |
|---|---|---|
| Pass height | 80 mm | |
| Maximum pass width | 300 mm | |
| Detection sensitivity 1 | Fe sphere | 0.4 mm dia |
| SUS304 sphere | 0.7 mm dia | |
| Belt width | 230 mm | |
| Display | 7-inch color TFT LCD | |
| Operation method | Touch panel (Start, Stop, and Home are direct push buttons) | |
| Preset memory | Maximum 200 | |
| Belt speed | 25 m/min (50 Hz), 30 m/min (60 Hz) | |
| Maximum product weight 2 | 3 kg (Can support up to 10 kg as an option) | |
| Power requirements 3, 4 | 100 Vac, single phase 50/60 Hz ; 110/115/120 Vac, single phase 60 Hz ; 200 Vac, single phase 50/60 Hz ; 220/230 Vac, single phase 50/60 Hz ; or 240 Vac, single phase 50 Hz. 160 VA, rush current 50 A (typ.) (20 ms or less) |
|
| Mass | 76 kg | |
| Environmental conditions | 0° to 40°C, relative humidity 30% to 85%, non-condensing | |
| Protection class | IP66 compliance | |
| Exterior | Indicator and detector head: stainless steel (SUS304) Conveyor frame and stand AHF type: metal (coating) / AHW type: stainless steel (SUS304) |
|
| Data output | USB port as an option (USB2.0), Ethernet interface as an option (10BASE-T, 100BASE-TX) | |
