| Model | KD7483FWH |
|---|---|
| Detection sensitivity 1 | Fe sphere and SUS sphere 0.6 mm dia. |
| X-ray output | Tube voltage 25 to 60 kV, tube current 0.3 to 7.0 mA, output 7.5 to 210 W |
| Safety | X-ray leakage maximum 1μSv/h or less, prevention of x-ray leakage by safety devices |
| Display | 15-inch color TFT LCD (unified image monitoring screen and operation screen) |
| Operation method | Touch panel (with touch buzzer) |
| Product size | 12mm or smaller (less than 1/3 of the minimum height of the inspection section) |
| Transfer pipe dimension | 3-inch (76.2mm) dia. |
| Inspection section pass height | 35mm (fixed) |
| Preset memory | Maximum 100 |
| Processing capacity(flow) | 11.0 kℓ/h |
| Power requirements 6, 7, 8 | 100 to 120 or 200 to 240 Vac, single phase, 50/60 Hz 1.6 kVA, rush current 80 A (typ.) (5 ms or less) |
| Mass | 340 kg |
| Environmental conditions 10 | Temperature: 0º to 35ºC (0º to 40ºC with optional air conditioner) relative humidity: 30% to 85%, non-condensing |
