| Model | KXS7522AWCLE |
|---|---|
| X-ray output | Tube voltage 30 to 80 kV, tube current 0.4 to 3.3 mA, output 12 to 100 W |
| Safety | X-ray leakage maximum 1.0 μSv/h or less, prevention of x-ray leakage by safety devices |
| Display | 15-inch color TFT LCD |
| Operation method | Touch panel (with touch buzzer) |
| Product size 1, 2 | Maximum width 240 mm, maximum height 120 mm |
| Belt width | 270 mm |
| Preset memory | 200 |
| Belt speed 3 Maximum product weight 4 |
10 to 60 m/min maximum 5 kg 60 to 90 m/min maximum 2 kg 0 to 40 m/min maximum 10 kg （optional） |
| Power requirements 5 | 100 to 240 AC, single phase, 50/60Hz 700 VA or less (tandard) |
| Mass 6 | 225 kg |
| Environmental conditions 7 | Temperature: 0º to 35ºC, Relative humidity: 30% to 85%, non-condensing |
| Protection class | Conveyor IP66, other parts IP40 |
| Exterior | Stainless steel (SUS304) |
