상세설명
| Plain End | Finned Area | |||||||
| Dimension (mm) | Dimension (mm) | |||||||
| Out Diameter | Wall Thickness (Average) | Corrugate Depth | Pitch | Depth Tolerance | Pitch Toleran | Inside | Outside | |
| Area(m2/m) | Area(m2/m) | |||||||
| Material | C12200, C4430, C6870, C7060, C7150 Tubes | |||||||
| BSCor-1 | 9.52 | 0.889 | 0.56 | 7.00 | +/-0.05 | +/-0.79 | ||
| BSCor-2 | 12.70 | 0.889 | 0.56 | 8.00 | +/-0.05 | +/-0.79 | ||
| BSCor-3 | 15.88 | 0.889 | 0.56 | 8.00 | +/-0.05 | +/-0.79 | ||
| BSCor-4 | 15.88 | 1.651 | 0.75 | 10.49 | +/-0.05 | +/-0.79 | ||
| BSCor-5 | 19.05 | 0.889 | 0.65 | 8.66 | +/-0.05 | +/-0.79 | ||
| BSCor-6 | 19.05 | 1.651 | 0.75 | 11.35 | +/-0.05 | +/-0.79 | ||
| BSCor-7 | 22.23 | 0.889 | 0.70 | 9.27 | +/-0.05 | +/-0.79 | ||
| BSCor-8 | 22.23 | 1.651 | 0.80 | 12.17 | +/-0.05 | +/-0.79 | ||
| BSCor-9 | 25.40 | 0.869 | 0.70 | 9.83 | +/-0.05 | +/-0.79 | ||
| BSCor-10 | 25.40 | 1.651 | 0.80 | 12.90 | +/-0.05 | +/-0.79 | ||
