1. LEAD PITCH : 2.54mm 2. Current Rating : 3AMP 3. Operation Temperature : -40℃ to +105℃ 4. Contact Resistance : 20mΩ Max. 5. Insulation Resistance : 1000MΩ Min. 6. Withstanding Voltage : AC 1000V 7. Insulator Material : Polyester(UL94V-0) Standard:PBT 8. Contact Material : Brass 9. Contact Plation : Au or Sn over 50u" Ni
