Model NoWYACR4-18.5 WYACR4-22 WYACR4-30 WYACR4-37 WYACR4-45 WYACR4-55 WYACR4-75 WYACR4-90 WYACR4-110 WYACR4-132 WYACR4-160 WYACR4-185 WYACR4-220 WYACR4-250 WYACR4-280 WYACR4-315 WYACR4-350 WYACR4-375
TYPE입력용(전원협조용)
정격(Rating)-
입력(Input)3상 380/440V
출력(Output)50~840A
용량(Capacity)18.5~375kW


• 사양 및 특징

• • Rating : 3Ø 380/440V / 50/60 Hz
  • Dielectric withstand : AC 3000V / 1min
  • Insulation resistance : DC 500V / 100MΩ
  • IP Class : IP20
  • Sound level : Less than 65db
  • Operating temp. : -20℃ ~ +40℃
