SPECIFICATIONS

• Valve Size: 1/2" ~ 2"
• Applicable Rating: ASME Class 900,1500, 2500, 4500
• Temperature: Max. . 500℃
• Code & Standard: API, BS, ASME, ASTM

  Designed by

  ASME B16.11 /16.25 /16.34 /16.5 /BS5352

• Constructions
  • End Connection: Socket-welded or Flanged Type
  • WB(=Welded Bonnet) Type
  • Full Bore /Reduce Bore
  • Rising Stem / Rising Hand Wheel
  • Manual or Motor Operated (Pneumatic, Electric, or Hydraulic)
